LED Panel Light
Product Features:
*Excellent replacement of traditional grill fixtures
*Luminous efficiency up to 100lm/W, durable and bright
*Uniform light without flickering
*CE compliant
*Body: Aluminium
*Cover: Iron Back Cover
Application for suspension/recessed/surface mounting installation with suitable accessories
  • product details
Description
  • L-PL-0606
  • L-PL-1206
  • L-PL-1203

Specification
Item
number
Voltage Watts Luminous Beam P.F. CCT CRI Lifetime Dimension Special
Flux angle
(V) (W) (lm) (°) K (hrs) (mm)
L-PL-0606 220-240V
100-240V
36W 3600lm 150° 0.9 3000K 80 25000 595*595*9 -
4000K
6500K
L-PL-0606-U 220-240V
100-240V
36W 3600lm 85° 0.9 3000K 80 25000 595*595*9 Anti-Glare
UGR19
4000K
6500K
L-PL-0606 220-240V
100-240V
40W 4000lm 150° 0.9 3000K 80 25000 595*595*9 -
4000K
6500K
L-PL-0606-U 220-240V
100-240V
40W 4000lm 85° 0.9 3000K 80 25000 595*595*9 Anti-Glare
UGR19
4000K
6500K
L-PL-0606 220-240V
100-240V
48W 4800lm 150° 0.9 3000K 80 25000 595*595*9 -
4000K
6500K
L-PL-0606 220-240V
100-240V
60W 4800lm 150° 0.9 3000K 80 25000 595*595*9/
620*620*9
-
4000K
6500K
L-PL-1203-U 220-240V
100-240V
36W 3600lm 85° 0.9 3000K 80 25000 295*1195*10.5 Anti-Glare
UGR19
4000K
6500K
L-PL-1203 220-240V
100-240V
40W 4000lm 150° 0.9 3000K 80 25000 295*1195*10.5 -
4000K
6500K
L-PL-1203-U 220-240V
100-240V
40W 4000lm 85° 0.9 3000K 80 25000 295*1195*10.5 Anti-Glare
UGR19
4000K
6500K
L-PL-1203 220-240V
100-240V
48W 4800lm 150° 0.9 3000K 80 25000 295*1195*10.5 -
4000K
6500K
L-PL-1203 220-240V
100-240V
60W 4800lm 150° 0.9 3000K 80 25000 295*1195*10.5 -
4000K
6500K
L-PL-1206 220-240V
100-240V
60W 6000lm 150° 0.9 3000K 80 25000 595*1195*10.5 -
4000K
6500K
L-PL-1206-U 220-240V
100-240V
60W 6000lm 85° 0.9 3000K 80 25000 595*1195*10.5 Anti-Glare
UGR19
4000K
6500K
L-PL-1206 220-240V
100-240V
70W 7000lm 150° 0.9 3000K 80 25000 595*1195*10.5 -
4000K
6500K
