Recessed LED Downlight-Bulbized Sunflower Series
Product Features:
*"Bulbized" technology increases up to 65% of the luminous flux
*Optical lens on each LED to guarantee a uniform light distribution
*Built-in driver ensures both a higher safety and a real flatness
*Modularized structure allows an easier SKD solution
  • product details
Description
  • L-DL-0130
  • L-DL-0120
  • L-DL-0220

Introduction:
With the successful debut of the Bulbized Sunflower downlight last year, WELLMAX has shown the world what we are capable of under 30 years' experience in lighting product development. The Sunflower that adopts the‘Bulbized’tech as well as Samsung LED  has led a new technology trend in industry.

Encouraged by the market, WELLMAX tried to extend the application of ‘Bulbized’ tech to a wider use, seeking for new breakthrough that can achieve the level of perfection in the field. Here, we bring out a new panel light - Bulbized LED panel light. High illumination with never-yellowing feature is the most attractive point of the product, with which you will draw your customers closer to your brand. And, what really wows our clients is that even with so many advantages, it can offer a more competitive price than the traditional one on the market.  Furthermore, the panel has a modular structure design which allows an easier assembly. It is very suitable for markets with SKD needs.

Specification
Item No. Voltage Watts Luminous
Flux
Beam angle P.F. CCT CRI Lifetime Dimension Hole size Dimmable
(V) (W) (lm) (°) (K) (hrs) Φ*L(mm) (mm)
L-DL-0120-
3W
220-240V
100-240V
3W 240lm 120° >0.5 3000K
4000K
6500K
≥80 25000 Φ90*24 Φ74 no
L-DL-0120-
6W
220-240V
100-240V
6W 480lm 120° >0.5 3000K
4000K
6500K
≥80 25000 Φ120*24 Φ108 no
L-DL-0120-
9W
220-240V
100-240V
9W 720lm 120° >0.5 3000K
4000K
6500K
≥80 25000 Φ150*24 Φ135 no
L-DL-0120-
12W
220-240V
100-240V
12W 960lm 120° >0.5 3000K
4000K
6500K
≥80 25000 Φ170*24 Φ158 no
L-DL-0120-
15W
220-240V
100-240V
15W 1200lm 120° >0.5 3000K
4000K
6500K
≥80 25000 Φ170*24 Φ158 no
L-DL-0120-
18W
220-240V
100-240V
18W 1440lm 120° >0.5 3000K
4000K
6500K
≥80 25000 Φ225*24 Φ206 no
L-DL-0120-
24W
220-240V
100-240V
24W 1920lm 120° >0.5 3000K
4000K
6500K
≥80 25000 Φ225*24 Φ206 no
L-DL-0120-
30W
220-240V
100-240V
30W 2400lm 120° >0.5 3000K
4000K
6500K
≥80 25000 Φ225*24 Φ206 no
L-DL-0220-3W 220-240V
100-240V
3W 240lm 120° >0.5 3000K
4000K
6500K
≥80 25000 86*86*24 75*75 no
L-DL-0220-
6W
220-240V
100-240V
6W 480lm 120° >0.5 3000K
4000K
6500K
≥80 25000 120*120*24 105*105 no
L-DL-0220-
9W
220-240V
100-240V
9W 720lm 120° >0.5 3000K
4000K
6500K
≥80 25000 150*150*25 135*135 no
L-DL-0220-
12W
220-240V
100-240V
12W 960lm 120° >0.5 3000K
4000K
6500K
≥80 25000 170*170*24 155*155 no
L-DL-0220-
15W
220-240V
100-240V
15W 1200lm 120° >0.5 3000K
4000K
6500K
≥80 25000 170*170*24 155*155 no
L-DL-0220-
18W
220-240V
100-240V
18W 1440lm 120° >0.5 3000K
4000K
6500K
≥80 25000 225*225*24 208*208 no
L-DL-0220-
24W
220-240V
100-240V
24W 1920lm 120° >0.5 3000K
4000K
6500K
≥80 25000 225*225*24 208*208 no
L-DL-0220-
30W
220-240V
100-240V
30W 2400lm 120° >0.5 3000K
4000K
6500K
≥80 25000 225*225*24 208*208 no
